Product Description

Neoteck HDMI 2.0 Audio Extractor

Notice Before Order:

1. It is not compatible with Netflix and YouTube video websites.

2. When select to 5.1 Channel mode, the SPDIF out will output 5.1 channel audio depends on whether the input source contains 5.1 channel audio:

a). If it contains, SPDIF OUT interface will output 5.1 channel audio signal while STEREO OUT interface output nothing.

b). If it not contains, SPDIF OUT and AUDIO OUT interface are all output 2 channel audio signal.

3. Can NOT be used with other converter, such as HDMI to DVI Converter.

4. Please sure your HDTV with HDMI(ARC) Port, then connect to ARC Adapter HDMI Output Port.

5. This HDMI ARC function is only available for optical port, not for 3.5mm headphone jack or RCA port.

6. Please open the ARC function on your TV and this ARC converter when you use it.



Neoteck HDMI 2.0 Audio Extractor

Neoteck HDMI 2.0 Audio Extractor



ARC Setting Methods:

Your TV HDMI (ARC)--->HDMI Cable--->HDMI Audio Extractor (HDMI Output Port) --->HDMI Audio Extractor Optical Output to your audio device



Neoteck HDMI 2.0 Audio Extractor



Specifications

Suppoort HDMI HDCP Version: HDCP 2.2

HDMI Input/Output Resolution: Up to 4K/60fs

Support HDMI Video Color Format: 2160P, 10/12 bits, 24/25/30Hz, 2160p, 10/12 bits, 50/60Hz

HDMI Audio Format: DTS-HD/Dolby-TrueHD/LPCM7.1/DTS/olby-AC3/DSD

SPDIF Digital Audio Formate: Dolby Digital(AC3)/DTS/LPCM

Input Output TMDS Signal: 0.5~1.5Vp-p(TTL)

Input Output DDC Signal: 5Vp-p(TTL)

DAC sampling frequency: 32~192 KHz

DAC bit rate: 16~24 Bit

RCA analog output (1KHz@0dB): 1V RMS

Signal to noise ratio @0dB(CC1R/ARM): ≥90dB

Distortion degree: ≤0.1%

Frequency response: 20HZ~20KHz

HDMI Input Cable Distance: ≤3m AWG26 HDMI Standard Cable

HDMI Output Cable Distance: ≤3m AWG26 HDMI Standard Cable

Max Working Current: 400mA

Power Adapter Format: AC 100V-240V 50/60HZ,DC 5V/1A

Operating Temperature Range: -10~+55℃

Storage Temperature Range: -20~+60℃

Case Dimension: 85×60.5×20(mm)

Weight: 124g
